R575 vs. R670 vs. R770: The main differences between RUCKUS Tri-Band Wi-Fi 7 Access Points
June 4, 2026 - It has been a while since the R770 was the only Wi-Fi 7 Access Point (AP) from RUCKUS. Almost every month a new AP is added, bringing the total—at the time of writing—to 10 Wi-Fi 7 models. From the R575 to the R370. We previously wrote an article about Dual-Band Wi-Fi 7. This time, we highlight the 3 flagships from RUCKUS: the R575, R670, and R770.
What do they have in common?
There is no wrong choice with RUCKUS. Whether you choose the R575 or the R770; all RUCKUS Tri-Band Wi-Fi 7 models have access to the 6 GHz band and support MLO and Preamble Puncturing. Check our previous article for more information. In short, it comes down to the Access Points being much faster and having a higher range than their Wi-Fi 6 predecessors.
In addition, RUCKUS also has various patented technologies, such as BeamFlex+ and ChannelFly. The former is a smart antenna technology that allows antennas to adjust their signal pattern based on the user's location. This ensures an (even) greater range and less interference. It is not for nothing that ABI Research called RUCKUS one of the most innovative Enterprise WLAN vendors on the market.
Key features
| RUCKUS R575 | RUCKUS R670 | RUCKUS R770 | |
| Target Market | Good | Better | Best |
| MU-MIMO | 2x2:2 on all bands (2.4, 5, and 6 GHz) | 2x2:2 on all bands (2.4, 5, and 6 GHz) or 4x4 on 5 GHz in dual-band | 4x4:4 on 5 GHz and 2x2:2 on 2.4 and 6 GHz |
| Max. Speed | 9.3 Gbps | 9.34 Gbps | 12.22 Gbps |
| Concurrent Users | 512 | 768 | 1024 |
| PoE | PoE+ (802.3at) | PoE+ (802.3at) | PoE++ (802.3bt) |
A solution for every situation
- Choose the R575 if you want to be ready for Wi-Fi 7 in a small to medium-sized office or retail environment.
- Choose the R670 if you are dealing with larger groups of concurrent users and are looking for maximum flexibility on existing PoE+ switches.
- Choose the R770 if top performance, maximum capacity on the 5 GHz band, and a 10 Gbps backhaul are required for locations with extreme crowds.
Now available at Alcadis
All 3 models are available immediately at Alcadis. In particular, the R575, which is still available in only a few places. Do you want to get started with this model? Act fast! If you are still unsure about which Wi-Fi 7 Access Point best fits your situation, get in touch with our RUCKUS specialists via sales@alcadis.nl or 030 – 65 85 125. We are happy to help you think through your options, so you can get off to a flying start.
